YOKOGAWA CW240 User Manual

5-14
IM CW240E
Frequency
Input frequency
40 to 70 Hz 99.99 Hz
Position of decimal point and unit
Power Factor
Measurement range
-1.000 to 0 to 1.000 1.000
Position of decimal point
Phase Angle
Measurement range
-180.0 to 180.0° 180.0
Position of decimal point and unit
● Electric Energy (Position of Decimal Point and unit)
The position of the decimal point and the unit of measurement for electric energy can
be set. This can be done by following GENERAL 2/2 of the SETUP screen.
Setting Item Description
Unit of interval electric
energy
INTERVAL ELECTRIC
ENERGY INDICATION
UNIT
Electric energy display
[wh DISPLAY]
Set the position of the decimal point and the unit of measurement
for integrated electric energy.
Unit of electric energy
ELECTRIC ENERGY
INDICATION UNIT
For demand measurements: Set the position of the decimal
point and the unit of measurement for interval electric energy.
Interval electric energy
display
INTERVAL
Wh DISP.
Contents of Settings
mWh/Wh/kWh/MWh/GWh
STANDARD
Determines and fixes the position of the decimal point and the unit
of measurement automatically according to the rated power. (Table 1)
AUTO
Shifts the position of the decimal point automatically (the unit of
measurement also changes). (Table 2)
Setting of decimal point
position
000.000/0000.00/00000.0/000000
Setting of measurement
unit
The maximum number of displayable digits for electric energy is 999999 (6 digits).
5.3 Ranges and Number of Digits
