Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
When the Record Length Is 12.5 k points
(This record length can be selected on all models)
Intpl: Interpolation Mode
Rep: Repetitive Sampling Mode
Settings
Time/div
When High Resolution mode is off When High Resolution mode is on
When Interleave mode is off When Interleave mode is on When Interleave mode is off When Interleave mode is on
Realtime Intpl/Rep Realtime Intpl/Rep Realtime Intpl/Rep Realtime Intpl/Rep
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
Sample
Rate
(S/s)
Record
Length
(Points)
500 s 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k 50 250 k
200 s 50 100 k 50 100 k 50 100 k 50 100 k 50 100 k 50 100 k
50 100 k 50 100 k
100 s 50 50 k 50 50 k 50 50 k 50 50 k 50 50 k 50 50 k 50 50 k 50 50 k
50 s 50 25 k 50 25 k 50 25 k 50 25 k 50 25 k 50 25 k 50 25 k 50 25 k
20 s 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k 62.5 12.5 k
10 s 125 12.5 k 125 12.5 k 125 12.5 k 125 12.5 k 125 12.5 k 125 12.5 k 125 12.5 k 125 12.5 k
5 s 250 12.5 k 250 12.5 k 250 12.5 k 250 12.5 k 250 12.5 k 250 12.5 k 250 12.5 k 250 12.5 k
2 s 625 12.5 k 625 12.5 k 625 12.5 k 625 12.5 k 625 12.5 k 625 12.5 k 625 12.5 k 625 12.5 k
1 s 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k 1.25 k 12.5 k
500 ms 2.5 k 12.5 k 2.5 k 12.5 k 2.5 k 12.5 k 2.5 k 12.5 k 2.5 k 12.5 k
2.5 k 12.5 k 2.5 k 12.5 k 2.5 k 12.5 k
200 ms 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k 6.25 k 12.5 k
100 ms 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k 12.5 k
50 ms 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k 25 k 12.5 k
20 ms 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k 62.5 k 12.5 k
10 ms 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k 125 k 12.5 k
5 ms 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k 250 k 12.5 k
2 ms 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k 625 k 12.5 k
1 ms 1.25 M 12.5 k 1.25 M 12.5 k 1.25 M 12.5 k 1.25 M 12.5 k
1.25 M 12.5 k 1.25 M 12.5 k 1.25 M 12.5 k 1.25 M 12.5 k
500 μs 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k 2.5 M 12.5 k
200 μs 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k 6.25 M 12.5 k
100 μs 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k 12.5 M 12.5 k
50 μs 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k 25 M 12.5 k
20 μs 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k 62.5 M 12.5 k
10 μs 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k 125 M 12.5 k
5 μs 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k 250 M 12.5 k
2 μs 625 M 12.5 k 625 M 12.5 k 625 M 12.5 k
625 M 12.5 k 625 M 12.5 k 625 M 12.5 k 625 M 12.5 k 625 M 12.5 k
1 μs 1.25 G 12.5 k 1.25 G 12.5 k 1.25 G 12.5 k 1.25 G 12.5 k 625 M 6.25 k 1.25 G 12.5 k 1.25 G 12.5 k 1.25 G 12.5 k
500 ns 1.25 G 6.25 k 2.5 G 12.5 k 2.5 G 12.5 k 2.5 G 12.5 k 625 M 3.125 k 2.5 G 12.5 k 1.25 G 6.25 k 2.5 G 12.5 k
200 ns 1.25 G 2.5 k 6.25 G 12.5 k 2.5 G 5 k 6.25 G 12.5 k 625 M 1.25 k 6.25 G 12.5 k 1.25 G 2.5 k 6.25 G 12.5 k
100 ns 1.25 G 1.25 k 12.5 G 12.5 k 2.5 G 2.5 k 12.5 G 12.5 k 625 M 625 12.5 G 12.5 k 1.25 G 1.25 k 12.5 G 12.5 k
50 ns 1.25 G 625 25 G 12.5 k 2.5 G 1.25 k 25 G 12.5 k 625 M 312.5 25 G 12.5 k 1.25 G 625 25 G 12.5 k
20 ns 1.25 G 250 62.5 G 12.5 k 2.5 G 500 62.5 G 12.5 k 625 M 125 62.5 G 12.5 k 1.25 G 250 62.5 G 12.5 k
10 ns 1.25 G 125 125 G 12.5 k 2.5 G 250 125 G 12.5 k 625 M 62.5 125 G 12.5 k 1.25 G 125 125 G 12.5 k
5 ns 1.25 G 62.5 125 G 6.25 k
2.5 G 125 125 G 6.25 k 625 M 31.25 125 G 6.25 k 1.25 G 62.5 125 G 6.25 k
2 ns 1.25 G 25 125 G 2.5 k 2.5 G 50 125 G 2.5 k 625 M 12.5 125 G 2.5 k 1.25 G 25 125 G 2.5 k
1 ns 1.25 G 12.5 125 G 1.25 k 2.5 G 25 125 G 1.25 k 625 M 6.25 125 G 1.25 k 1.25 G 12.5 125 G 1.25 k
Values outside of the thick borders have been calculated in real-time sampling mode.
: Roll Mode
