Page #93 background imageLoading...
Page #93 background image
5-16
IM 710105-03E
5.9 Auxiliary I/O Section
External Trigger Input (TRIG IN)
Item Specifications
Connector type BNC
Input bandwidth
*
DC to 100 MHz
Input impedance Approx. 1 MΩ, approx. 20 pF
Maximum input voltage ±40 V (DC + ACpeak) or 28 Vrms
(At 1 MHz and higher, the voltage decreases at 20 dB/decade down to ±5 V (DC+ACpeak) or 3.5
Vrms.)
Input range ±2 V (DLM2024, DLM2034, DLM2054).
±1 V (for the ±1 V range on the DLM2022, DLM2032, DLM2052).
±10 V (for the ±10 V range on the DLM2022, DLM2032, DLM2052).
Trigger level ±2 V. The resolution is 5 mV (DLM2024, DLM2034, DLM2054).
±1 V. The resolution is 5 mV (for the ±1 V range on the DLM2022, DLM2032, DLM2052).
±10 V. The resolution is 50 mV (for the ±10 V range on the DLM2022, DLM2032, DLM2052).
* Values measured under standard operating conditions (see section 5.11 for details) after a 30-minute warm-up.
Trigger Output (TRIG OUT)
Item Specifications
Connector type BNC
Output level 3.3 V CMOS
Output impedance Approx. 50Ω
Output logic Negative logic and positive logic switchable
Output delay 50 ns max.
Output hold time
Negative logic: Low level: 800 ns min. High level: 50 ns min.
Positive logic: High level: 800 ns min. Low level: 50 ns min.
Probe Interface Terminal
Item Specifications
Output terminals
DLM2022, DLM2032, DLM2052: 3
DLM2024, DLM2034, DLM2054: 4
Output voltage ±12 V (up to 1.2 A in combination with the rear-panel probe power terminal), ±5 V (up to 800 mA
total)
Usable probes Active probes (701912, 701913, 701914), differential probes (701923, 701924, 701927),
current probes (701928, 701929)
Probe Power Terminal (/P2 and /P4 Option)
Item Specifications
Output terminals
DLM2022, DLM2032, DLM2052: 2 (/P2 option)
DLM2024, DLM2034, DLM2054: 4 (/P4 option)
Output voltage ±12 V (up to 1.2 A in combination with the probe interface terminal)
Usable probes and deskew
signal sources
FET probe (700939), current probe (701930, 701931, 701932, 701933), differential probes (700924,
700925, 701920, 701921, 701922, 701926), deskew signal source (701936)
GO/NO-GO Output
Item Specifications
Connector type RJ-12 modular jack
Output signal GO OUT, NO-GO OUT
Output level TTL compatible
Compliant cable Four-wire modular cable
Video Signal Output (VIDEO OUT)
Item Specifications
Connector type D-sub 15 pin (receptacle)
Output type Analog RGB output
Output resolution XGA-compliant output, 1024 × 768 dots, approx. 60-Hz Vsync (66-MHz dot clock frequency)
