2.8 Loading Roll Paper into the Built-In Printer (Option)
Attaching the Roll Paper
CAUTION
• Do not touch the print head. If you do, you may burn yourself.
• Do not touch the roll paper cutter section at the end of the printer cover. Doing
so may cause injury.
French
ATTENTION
• Ne pas toucher la tête d’impression. Vous pourriez vous brûler.
• Ne pas toucher la section du coupe-papier à l’extrémité du cache de l’imprimante.
Vous pourriez vous blesser.
Raise the handle.
Set the roll paper with the same orientation
as shown in the figure
OPEN COVER
button
Printer cover
Press the OPEN COVER button
to open the printer cover.
Roll paper cutter section
Print head
Close the cover and press LOCK on the
center of the cover until you hear a click.
Guide
1. 2.
3.
4.
5.
Align the ends of the roll paper with
the guides and set the roll in place.
