YOKOGAWA DLM2000 Series Operation Guide

5-15
IM 710105-03E
Specifications
1
2
3
4
5
App
Index
5.6 Built-in Printer (/B5 Option)
Item Specifications
Print system Thermal line dot system
Dot density 8 dots/mm
Sheet width 112 mm
5.7 Storage
Internal Memory
Item Specifications
Media type SD memory card
Memory size
Standard model: Approx. 300 MB
/C8 option: Approx. 1.8 GB
/C9 option: Approx. 7.2 GB
USB Storage Device
Item Specifications
Compatible USB storage
devices
Mass storage device compatible with USB Mass Storage Class Ver. 1.1
Available space 2 TB
Partition format: MBR, format type: FAT32/FAT16
* See section 5.8, "USB for Peripherals."
5.8 USB for Peripherals
Item Specifications
Connector type USB type A (receptacle)
Electrical and mechanical
specifications
USB Rev. 2.0 compliant
Supported transfer modes LS (Low Speed; 1.5 Mbps), FS (Full Speed; 12 Mbps), HS (High Speed; 480 Mbps)
Ports 2
Power supply 5 V, 500 mA (for each port)
Compatible devices Mouse devices that comply with USB HID Class Ver. 1.1
104 or 109 (Japanese) keyboards that comply with USB HID Class Ver. 1.1
Supports Epson inkjet printers and HP inkjet printers that are compatible with USB Printer Class
Ver. 1.0.
Mass storage device compatible with USB Mass Storage Class Ver. 1.1.
USB HUB device
No. of connectable devices Hub: 1 per port
Mouse, keyboard, and printer: 1 each
Mass storage devices: 4
Up to six devices can be connected including the hub
