5-18
IM 710105-03E
5.11 General Specifications
Item Specifications
Standard operating
conditions
Ambient temperature: 23 ± 5°C
Ambient humidity: 55 ± 10%RH
Supply voltage and
frequency errors:
Within 1% of rating
Warm-up time At least 30 minutes
Storage environment Temperature: –20 to 60°C
Humidity: 20 to 80%RH (no condensation)
Altitude: 3000 m or less
Operating environment Temperature: 5 to 40°C
Humidity: 20 to 80%RH (when the printer is not used; no condensation)
35 to 80%RH (when the printer is used; no condensation)
Altitude: 2000 m or less
Recommended calibration
period
One year
Rated supply voltage 100 to 240 VAC
Permitted supply voltage
range
90 to 264 VAC
Rated supply frequency 50/60 Hz
Permitted supply voltage
frequency range
48 to 63 Hz
Power fuse Built in (not replaceable)
Maximum power
consumption
170 VA (when the printer is used)
Withstand voltage (between
the power supply and case)
1.5 kVAC for 1 minute
Insulation resistance
(between the power supply
and case)
500 VDC, 10 MΩ or more
External dimensions 226 mm (W) × 293 mm (H) × 193 mm (D) when the printer cover is closed; excluding protrusions
Weight Approx. 4.2 kg (excluding options)
Instrument cooling method Forced air cooling; inlet on the left side, outlet on the rear
Installation position Horizontal
Battery backup The clock is backed up with the internal lithium battery.
Battery life: Approx. five years (at an ambient temperature of 25°C)
