Installation position
Place the instrument in a horizontal position (see the figure below).
Rubber stoppers can be attached to the four feet on the bottom of the DLM2000. Four
rubber stoppers are included with the DLM2000.
WARNING
Do not place the instrument in any position other than those shown in the above
figures. Also, do not stack the instrument.
French
AVERTISSEMENT
Ne pas placer l’instrument dans des positions autres celles indiquées ci-dessus. Ne
pas empiler l’instrument.
2.2 Installing the Instrument
