YOKOGAWA DLM2000 Series Operation Guide

iv
IM 710105-03E
MODEL SUFFIX
1
Specifications
/F10
/F11
/EX22
/EX24
/EX52
/EX54
PSI5 analysis (4ch model only)
SENT + PSI5 analysis (4ch model only)
Attach two 701946 probes (2ch, 200 MHz model only)
Attach four 701946 probes (4ch, 200 MHz model only)
Attach two 701946 probes (2ch, 350/500 MHz model only)
Attach four 701946 probes (4ch, 350/500 MHz model only)
1 For products whose suffix code contains “Z,” an exclusive manual may be included. Please
read it along with the standard manual.
2 Make sure that the attached power cord meets the designated standards of the country and
area that you are using it in.
Note
The SUFFIX (suffix code) inscribed in the name plate on the DLM2000 case indicates the
installed options at the time of factory shipment. After you add options through additional option
licenses, check the options on the DLM2000 overview screen.*
* For details on additional option licenses, see “Overview (Overview)” in chapter 22, “Other
Features” of the features guide, IM 710105-01E.
NO. (Instrument Number)
When contacting the dealer from which you purchased the instrument, please give them
the instrument number.
Standard Accessories
The standard accessories below are supplied with the instrument. Check that all contents
are present and that they are undamaged.
Item Model or Part
No.
Quantity Specifications and Notes
Power cord
1
A1006WD
A1009WD
A1054WD
A1024WD
A1064WD
A1088WD
1 UL/CSA Standard
VDE Standard
BS Standard
AS Standard
GB Standard
NBR standard
Panel sheet See the next
page.
1 Japanese, Chinese, German, French, Korean, Italian,
or Spanish
500-MHz passive
probe
2
701939 4 (2) The 710120 and 710130 come with four probes, and
the 710115 and 710125 come with two probes.
200-MHz passive
probe
3
701938 4 (2) The 710110 comes with four probes, and the 710105
comes with two probes.
Rubber feet B9989EX 1 –
Soft case B8059GG 1 –
Printer roll paper
4
B9988AE 1 –
Front cover B8059EP 1 –
Manuals
Printed
manuals
IM 710105-03E 1 Operation Guide (this guide)
IM 710105-92 1 Document for China
PIM 113-01Z2 1 List of worldwide contacts
Manual CD B8059RZ 1 Contains PDFs of the user’s manuals
(For the types of manuals that CD contains, see the
next page.)
Standard accessories are not covered by warranty of this instrument.
UL/CSA Standard
A1006WD
VDE Standard
A1009WD
BS Standard
A1054WD
AS Standard
A1024WD
D F Q R
Power cord (one cord that matches the suffix code is included)
1
GB Standard
A1064WD
H N
NBR Standard
A1088WD
Checking the Contents of the Package
