3-13
IM 710105-03E
Basic Operations
3
Settings after the Execution of Auto Setup
CH1 to CH4 settings
Position 0 div
Coupling DC
BW FULL
Offset 0 V
Invert OFF
Acquisition settings
Record Length The same as the value used before you executed auto setup
However, if the record length is such that the DLM2000 cannot
acquire waveforms in Single mode, the record length is set to
the maximum record length at which the DLM2000 can acquire
waveforms repeatedly.
Mode Normal
Hi Resolution OFF
Interleave OFF
Sampling Mode Interpolation
Trigger settings
Trigger type Edge
Mode Auto
HoldOff 20 ns
Delay 0 s
Position 50%
Slope Rising
Coupling DC
HF Rejection OFF
Noise Rejection OFF
Window OFF
Settings that depend on the input signal
CH On/Off On if the DLM2000 detects a voltage of ±20 mV (1:1) or higher and
Off otherwise
V/div Selects the range with the highest sensitivity that does not exceed
±3.5 divisions
Trigger Level Center
Trigger Source The channel with the lowest frequency among the signals whose
amplitude (Max – Min) is at least 1 division
Time/div The fastest sweep range that allows at least two periods of the
fastest signal among the signals whose amplitude is at least 1
division to be observed. The sweep range must be at least 5 ms/
division.
The values of settings not listed here do not change.
3.5 Performing Auto Setup
To Next Page
