Item Specifications
Maximum record length Maximum record length for which repetitive acquisitions are possible
No options: 1.25 M points
On models with the /M1 option: 6.25 M points
On models with the /M2 option: 12.5 M points
On models with the /M3 option: 25 M points
Maximum record length for which a single acquisition is possible. Values inside parentheses apply
when interleave mode is on.
No options: 6.25 M points (12.5 M points)
On models with the /M1(S) option: 25 M points (62.5 M points)
On models with the /M2 option: 62.5 M points (125 M points)
On models with the /M3 option: 125 M points (250M points)
1 Values measured under standard operating conditions (see section 5.11 for details) after a 30-minute warm-up and calibration.
2 Values for repeating phenomena.
The single-shot frequency bandwidth is from DC to the sampling frequency/2.5 or is the frequency bandwidth of the repeating
phenomena, whichever is less.
3 Values when the input section is shorted, the acquisition mode is set to Normal, accumulation is set to off, and the probe
attenuation is set to 1:1.
4 Typical values represent typical or average values. They are not strictly warranted.
Logic Signal Input
Item Specifications
Usable probes 701980, 701981, 701988, 701989 (8-bit input)
Number of inputs 8
Nondestructive maximum
input voltage
701980, 701981, 701989: ±40 V (DC + ACpeak) or 28 Vrms
701988: ±42 V (DC + ACpeak) or 29 Vrms
For information about derating based on frequency, see the respective logic probe user's manual.
When using the 701980 When using the 701981 When using the 701988 When using the 701989
Input range ±40 V ±10 V ±40 V Threshold level ± 6 V
Minimum input voltage 500 mVp-p 500 mVp-p 500 mVp-p 300 mVp-p
Maximum toggle frequency
1
100 MHz 250 MHz 100 MHz 250 MHz
Input impedance (typical
value
3
)
1 MΩ/approx. 10 pF 10 kΩ/approx. 9pF 1 MΩ/approx. 10 pF Approx. 100 kΩ/approx.
3 pF
Variable threshold level
range
±40 V ±10 V ±40 V ±6 V
Threshold level setting Same value for all 8 bits Same value for all 8 bits Same value for all 8 bits Different values for
each of the 8 bits
Threshold level resolution 0.1 V 0.1 V 0.05 V 0.05 V
Threshold level accuracy
1
±(0.1 V + 3% of setting) ±(0.1 V + 3% of setting) ±(0.1 V + 3% of setting) ±(0.1 V + 3% of setting)
Hysteresis voltage (typical
value
3
)
80 mV 50 mV 100 mV When noise rejection is
off: 100 mV
When noise rejection is
on: 250 mV
Minimum pulse width 5 ns 2 ns 5 ns 2 ns
Maximum sample rate Real-time sampling mode. Values inside parentheses are for high resolution mode
2
When interleave mode is on: Unable to acquire logic waveforms
When interleave mode is off: 1.25 GS/s (625 MS/s)
Repetitive sampling mode: 125 GS/s
Interpolation sampling mode: 125 GS/s (Pulse interpolation for logic
waveforms)
Maximum record length Maximum record length for which repetitive acquisitions are possible
No options: 1.25 M points
On models with the /M1 option: 6.25 M points
On models with the /M2 option: 12.5 M points
On models with the /M3 option: 25 M points
Maximum record length for which a single acquisition is possible.
No options: 6.25 M points
On models with the /M1 option: 25 M points
On models with the /M2 option: 62.5 M points
On models with the /M3 option: 125 M points
1 Under standard operating conditions (see section 5.11 for details) after a 30-minute warm-up.
2 Resolution only improves for analog waveforms.
3 Typical values represent typical or average values. They are not strictly warranted.
