YOKOGAWA DLM2000 Series Operation Guide

vi
IM 710105-03E
Optional Accessories (Sold Separately)
The optional accessories below are available for purchase separately. For information
and ordering, contact your nearest YOKOGAWA dealer.
• Use the accessories specified in this manual. Moreover, use the accessories of this
product only with Yokogawa products that specify them as accessories.
• Use the accessories of this product within the rated range of each accessory. When
using several accessories together, use them within the specification range of the
accessory with the lowest rating.
Item
Model/
Part No.
Min.
Q'ty
Specifications Manual No.
PBDH1000 differential probe with
YOKOGAWA probe interface
701924 1
DC to 1-GHz bandwidth, 1 MΩ,
±35 V maximum
IM 701924-01E
PBDH0150 differential probe with
YOKOGAWA probe interface
701927 1
DC to 150-MHz bandwidth,
±1400 V maximum
IM 701927-01EN
PBC100 current probe with
YOKOGAWA probe interface
701928 1
DC to 100-MHz bandwidth,
30 Arms
IM 701928-01E
PBC050 current probe with
YOKOGAWA probe interface
701929 1
DC to 50-MHz bandwidth,
30 Arms
Passive probe
701938 1 DC to 200-MHz bandwidth, 10 MΩ IM 701938-01E
701939 1 DC to 500-MHz bandwidth, 10 MΩ IM 701939-01E
Miniature Passive Probe 701946 1 DC to 500-MHz bandwidth, 10 MΩ IM 701946-01EN
Passive probe (wide temperature
range)
702906 1
DC to 200 MHz bandwidth, 10 MΩ,
operating temperature range:
- 40°C to +85°C (excluding the phase
adjustment side)
IM 702906-01EN
PBL100 logic probe 701988 1 100-MHz toggle frequency, 1 MΩ IM 701988-01E
PBL250 logic probe 701989 1 250-MHz toggle frequency, 100 kΩ IM 701989-01E
100:1 high-voltage passive probe
701944 1
DC to 400-MHz bandwidth, 1000 Vrms,
1.2 m in length
IM 701944-01E
701945 1
DC to 250-MHz bandwidth, 1000 Vrms,
3 m in length
FET probe
*
700939 1 900-MHz bandwidth, 2.5 MΩ, 1.8 pF IM 700939-01E
Differential probe
*
700924 1
DC to 100-MHz bandwidth,
±1400 V maximum
IM 700924-01E
700925 1
DC to 15-MHz bandwidth,
±500 V maximum
IM 700925-01E
701920 1
DC to 500-MHz bandwidth,
±30 V maximum (common-mode input)
IM 701920-01E
701921 1
DC to 100-MHz bandwidth,
±700 V maximum
IM 701921-01E
701922 1
DC to 200-MHz bandwidth,
±60 V maximum (common-mode input)
IM 701922-01E
701926 1
DC to 50-MHz bandwidth,
±7000 V maximum (common-mode input)
IM 701926-01E
Current probe
*
701917 1 DC to 50 MHz bandwidth, 5 Arms IM 701917-01EN
701918 1 DC to 120 MHz bandwidth, 5 Arms IM 701917-01EN
701930 1 DC to 10-MHz bandwidth, 150 Arms IM 701930-01E
701931 1 DC to 2-MHz bandwidth, 500 Arms IM 701931-01E
701932 1 DC to 100-MHz bandwidth, 30 Arms IM 701932-01E
701933 1 DC to 50-MHz bandwidth, 30 Arms IM 701933-01E
PBL500 5 GHz low capacitance
probe
701974 1 — IM 701974-01E
Deskew signal source 701936 1
Approx. 0 to 5 V, approx. 0 to 100 mA,
approx. 0 to 1 A, approx. 15 kHz
IM 701936-01EN
Mini clip adapter 700971 1 set — —
BNC adapter 700972 1 — —
Logic probe accessory kit 701909 1 set For the 701989 —
Probe stand 701919 1 — IM 701919-01E
PCB adapter 366945 1 set For 701939 passive probes —
Solder-in adapter 366946 1 set For 701939 passive probes —
