YOKOGAWA DLM2000 Series Operation Guide

5-5
IM 710105-03E
Specifications
1
2
3
4
5
App
Index
Item Specifications
CAN FD:
6
Triggers on CAN FD bus signals
The source can be set to a signal from CH1 to CH4.
Modes: SOF, Error Frame, ID, ID OR
Bit Rate: Arbitration phase
250 k, 500 k, 1 Mbps, User Define
For User Define, you can set a value from 20 k to 1 Mbps in
0.1-kbps steps.
Data phase
500 k, 1 Mbps, 2 Mbps, 4 Mbps, 5 Mbps, 8 Mbps, User Define
For User Define, you can set a value from 250 k to 10 Mbps in
0.1-kbps steps.
LIN:
6
Triggers on a LIN (Local Interconnect Network) bus signal
The source can be set to a signal from CH1 to CH4.
Modes: Break Synch, Error, ID/Data, ID OR
Bit Rate: 1200, 2400, 4800, 9600, 19200 bps, User Define
For User Define, you can set a value from 1 k to 20 kbps in 0.01-kbps steps.
SENT:
6
Triggers on SENT signals (J2716 JAN2010 and earlier)
The source can be set to a signal from CH1 to CH4 or from logic bits 0 to 7.
2
Modes: Every Fast CH
Clock period: 1 μs to 100 μs (resolution: 0.01 μs)
PSI5 Airbag:
6
Triggers on PSI5 Airbag signal
The source can be set to a signal from CH1 to CH4.
Mode: Sync, Start Bit, Data
Bit Rate: 125kbps, 189kbps, User Define
For User Define, you can set a value from 10.0 k to 1000.0 kbps in 0.1-kbps
steps.
UART:
6
Triggers on a UART (RS232) signal
The source can be set to a signal from CH1 to CH4 or from logic bits 0 to 7.
2
Modes: Every Data, Error, Data
Formats: 8-bit data (no parity bit), 7-bit data + parity bit,
8-bit data + parity bit
Bit Rate: 1200, 2400, 4800, 9600, 19200 bps, 38400 bps, 57600 bps,
115200 bps, User Define
For User Define, you can set a value from 1 k to 1000 kbps in 0.1-kbps steps.
I2C:
6
Triggers on an I2C bus signal.
The source can be set to a signal from CH1 to CH4 or from logic bits 0 to 7.
2
Modes: Every Start, Adr Data, NON ACK, General Call, Start byte,
HS Mode
SPI:
6
Triggers on an SPI (Serial Peripheral Interface) bus signal
The source can be set to a signal from CH1 to CH4 or from logic bits 0 to 7.
2
Modes: 3wire, 4wire
User Define: Triggers on a general-purpose serial communication signal
The source can be set to a channel from CH1 to CH4.
1
Data channel, chip select channel, clock channel, and latch channel can be
specified.
Bit Rate: 1 k to 200 Mbps (with clock)
1 k to 49.5 Mbps (without clock)
Data Size: 1 to 128 bits
1 CH1 and CH2 on the DLM2022, DLM2032, and DLM2052.
2 Logic only available on the DLM2024, DLM2034, and DLM2054.
3 Values measured under standard operating conditions (see section 5.11 for details) after a 30-minute warm-up and calibration.
4 Values measured under standard operating conditions (see section 5.11 for details) after a 30-minute warm-up.
5 Typical values represent typical or average values. They are not strictly warranted.
6 FlexRay, CAN, CAN FD, LIN, SENT, PSI5, UART, I2C, and SPI are options for 4-channel models.
5.2 Triggering Section
