Item Specifications
TV: Triggers on the specified field number, line number, or polarity in video signals
of various broadcasting systems.
The source can be set to a channel from CH1 to CH4.
1
Mode: NTSC: Triggers on an NTSC (525/60/2) signal
PAL: Triggers on a PAL (625/50/2) signal
SDTV: Triggers on an SDTV (480/60p) signal
HDTV: Triggers on the following HDTV signals
1080/60p, 1080/60i, 1080/50ip, 1080/25p,
1080/24p, 1080/24sF, 720/60
USER Def: You can trigger on any TV signal by selecting
standard or high definition, setting the H sync
period, and setting the sync guard.
Sync guard can be set to a value from 60 to 90%
of the H sync value in 1% steps.
Polarity: Pos, Neg
HF Rej: NTSC/PAL: 300 kHz (fixed)
SDTV/HDTV: OFF (fixed)
User Def: Off or 300 kHz
Line: 5 to 1054 (NTSC), 2 to 1251 (PAL), 8 to 2251 (SDTV),
2 to 2251 (HDTV), 2 to 2251 (USER), ALL
Field: 1, 2, X
Frame Skip: 1, 2, 4, 8
AB trigger Able to trigger on the combination of triggers A and B
Some trigger types cannot be specified depending on the AB trigger type as shown below.
(see Trigger Type (A trigger))
OFF: Triggers only on the trigger A conditions (the trigger B conditions are not used).
A Delay B: After the trigger A conditions are met and the specified amount of time elapses,
the DLM2000 triggers when the trigger B conditions are met.
Trigger B cannot be set to Edge OR, Width, CAN FD, SENT, PSI5 Airbag, or TV.
Delay value: 10 ns to 10 s
A to B(N): After the trigger A conditions are met, the DLM2000 triggers when the trigger B
conditions are met N times.
Trigger B cannot be set to Edge OR, Width, CAN FD, SENT, PSI5 Airbag, or TV.
N value: 1 to 10
9
Dual Bus: The DLM2000 triggers when condition A or B of the serial bus trigger (except
CAN FD, SENT and PSI5 Airbag) is met.
5.2 Triggering Section
