YOKOGAWA GX10 User Manual

2-32
IM 04L51B01-17EN
SCalibIO
Calibration Correction
Sets the calibration correction for AI channels.
Disable Calibration Correction
Syntax
SCalibIO,p1,p2
p1
Channel number
p2
Linearizer mode (Off)
Use Calibration Correction (Linearizer approximation,
linearizer bias)
Syntax
SCalibIO,p1
p1
Channel number
p2
Linearizer mode
Appro
Linearizer approximation
Bias
Linearizer bias
p3
Number of set points (2 to 12)
P4
Input value of set point 1
p5
Output value of set point 1
p6
Input value of set point 2
p7
Output value of set point 2
p8
Input value of set point 3
p9
Output value of set point 3
p10
Input value of set point 4
p11
Output value of set point 4
p12
Input value of set point 5
p13
Output value of set point 5
p14
Input value of set point 6
p15
Output value of set point 6
p16
Input value of set point 7
p17
Output value of set point 7
p18
Input value of set point 8
p19
Output value of set point 8
p20
Input value of set point 9
p21
Output value of set point 9
p22
Input value of set point 10
p23
Output value of set point 10
p24
Input value of set point 11
p25
Output value of set point 11
p26
Input value of set point 12
p27
Output value of set point 12
Use Calibration Correction (Correction coefficient) (/
AH)
Syntax
SCalibIO,p1,p2,p3,p4,p5,p6,p7,p8,p
9,p10,p11,p12,p13,p14,p15,p16,p17,
p18,p19p,20p,p21,p22,p23,p24,p25,p
26,p27,p28,p29,p30,p31,p32,p33,p34
,p35,p36,p37,p38,p39
p1
Channel number
p2
Mode
Correct
Correction coefficient
p3
Number of correction points (2 to 12)
p4
Input value of uncorrected value 1
p5
Instrument correction coefficient 1
p6
Sensor correction coefficient 1
p7
Input value of uncorrected value 2
p8
Instrument correction coefficient 2
p9
Sensor correction coefficient 2
p10
Input value of uncorrected value 3
p11
Instrument correction coefficient 3
p12
Sensor correction coefficient 3
p13
Input value of uncorrected value 4
p14
Instrument correction coefficient 4
p15
Sensor correction coefficient 4
p16
Input value of uncorrected value 5
p17
Instrument correction coefficient 5
p18
Sensor correction coefficient 5
p19
Input value of uncorrected value 6
p20
Instrument correction coefficient 6
p21
Sensor correction coefficient 6
p22
Input value of uncorrected value 7
p23
Instrument correction coefficient 7
p24
Sensor correction coefficient 7
p25
Input value of uncorrected value 8
p26
Instrument correction coefficient 8
p27
Sensor correction coefficient 8
p28
Input value of uncorrected value 9
p29
Instrument correction coefficient 9
p30
Sensor correction coefficient 9
p31
Input value of uncorrected value 10
p32
Instrument correction coefficient 10
p33
Sensor correction coefficient 10
p34
Input value of uncorrected value 11
p35
Instrument correction coefficient 11
p36
Sensor correction coefficient 11
p37
Input value of uncorrected value 12
p38
Instrument correction coefficient 12
p39
Sensor correction coefficient 12
Query
SCalibIO[,p1]?
Example Set three set points on channel 0001
(measurement range: 0 to 1.0000 V). Set the
set points as follows: when the input value is 0
V, the output value is 0.0010 V; when the input
value is 0.5000 V, the output value is 0.5020
V; when the input value is 1.0000 V, the output
value is 0.9970 V.
SCalibIO,0001,Appro,3,0,10,5000,
5020,10000,9970
Description
• If p2=Off, you cannot set p3 or subsequent
parameters.
• You cannot specify set points beyond the number of
points specified by p3.
• If the AI channel input type (p2 of SRangeAI) is set
to Skip or DI, you cannot specify anything other than
p2=Off.
