Commands and Responses
1
2
App
Conditions p7 p8 p9 p10 p11
p6 Action
Type
Value Source
Element
Number
Action
Detail
1
Action
Detail 2
Action
Detail 3
Rising,
Falling,
Edge
Recording Memory - Start,
Stop
-
ALL, batch
group
number
*4
Math (math
channel)
Math - Start,
Stop,
Reset
- -
Display rate
switch
[GX/GP]
RateChange 1, 2 Reset -
ALL, batch
group
number
*4
Flag Flag 1 to 20 - - -
Manual
sample
ManualSample - - - -
DO output
1
DO Channel
number
Off, On - -
Output to
an internal
switch
2
SW Channel
number
Off, On - -
Alarm ACK AlarmACK - - - -
Snapshot
[GX/GP]
Snapshot - - - -
Time
adjustment
TimeAdjust - - - -
Display data
save
SaveDisplay - - -
ALL, batch
group
number
*4
Event data
save
SaveEvent 1 - - ALL, batch
group
number
*4
Event
trigger
3
Trigger 1, 2 - - -
Message Message 1 to 100 All,
Select
Display
group
number
*4
Batch
group
number
*4
Display
group
change
[GX/GP]
GroupChange Display
group
number
*4
- - Batch
group
number
*4
Relative
timer reset
TimerReset 1 to 12 - - -
Settings
load
ConfigLoad 1 to 10 - - -
Settings
save [GM]
ConfigSave 1 to 10 - - -
Favorite
screen
display [GX/
GP]
PlayList 1 to 20 - - -
Pattern file
load
5
ProgPatLoad 1 to 10 - - -
Both Recording
start/stop
MemoryStartStop - - -
ALL, batch
group
number
*4
Math start/
stop
MathStartStop - - - -
Display rate
switch 1/2
[GX/GP]
RateChange1_2 - - -
Flag On/Off FlagOn_Off 1 to 20 - - -
DO On/Off
1
DOOn_Off Channel
number
- - -
Internal
switch on/
off
2
SWOn_Off Channel
number
- - -
1 Can be output only to DO whose type is set to Manual.
2 Can be output only to SW whose type is set to Manual.
3 Valid when the advanced security function (/AS) is disabled.
4 For the setting range, see section 2.3.2, “Parameter Notation and
Range.”
5 This is valid only for the program control function (/PG).
Query
SEventAct[,p1]?
Invalid parameters are returned as blanks in
queries.
Example Execute memory start on the rising edge of the
remote control input (channel 0101). Use event
action number 2.
SEventAct,2,On,DI,0101,,Rising,Mem
ory,,Start
Description
• There are limitations to event and action
combinations. For details, see section 1.14 in the
Model GX10/GX20/GP10/GP20 Paperless Recorder
User’s Manual (IM 04L51B01-01EN) or section 2.15,
“Configuring the Event Action Function,” in the Data
Acquisition System GM User’s Manual (IM 04L55B01-
01EN).
• Write only delimiters (commas) for irrelevant
parameters (invalid even if a value is specified).
• Event type “DI” is the channel of the DI module that
has been set to remote module (SModeDI command).
• You can specify p3 = Status and p6 = Both when
an item that can be specified as an action (flag, DO
channel, or internal switch) is valid.
• Math channel and flag are an option (/MT).
• Communication channels are an option (/MC).
2.4 Setting Commands
