YOKOGAWA GX10 User Manual

2-68
IM 04L51B01-17EN
SHomeKind
Standard Screen [GX/GP]
Set the standard screen.
For Multi Panel
Syntax
SHomeKind,p1,p2,p3
p1
Screen type (Multi)
p2
Multi panel number (1 to 20)
p3
Batch group number (1 to the number
used)
p3 is valid when the multi batch function (/
BT) is enabled.
For Screens other than Multi Panel
Syntax
SHomeKind,p1,p2,p3
p1
Screen type
Trend
Trend
Digital
Digital
Bar
Bar graph
Overview
OVERVIEW
Alarm
Alarm summary
Message
Message summary
Memory
Memory summary
Report
Report summary
Modbus-M
Modbus master status
Mosbus-C
Modbus client status
Watt
WT communication
status
Switch
Internal switch/relay
status
Action-Log
Event log
Error-Log
Error log
Commu-Log
Communication log
Ftp-Log
FTP log
Web-Log
Web log
Mail-Log
Mail log
Modbus-Log
Modbus log
Sntp-Log
SNTP log
Dhcp-Log
DHCP log
SLMP-Log
SLMP log (/E4)
Network
Network information
SLMP-C
SLMP client status (/E4)
Reminder
Reminder (/AH)
Setting
Settings
ControlGroup
Control group
ControlSummary
Control summary
ControlAlarm
Summary
Control alarm summary
ControlOverview
Control overview
SaveLoad
Save load
SystemInfo
System information
Custom
Customized display
screen
Display
Batch
Overview
Batch overview (/BT)
Tuning
Tuning
ProgramSelect
Program selection (/PG)
ProgramRun
Program operation (/
PG)
p2
Display group number
(when p1 is not CustomDisplay)
Customized display screen number (1 to
30)
(when p1 is CustomDisplay)
Control group number (1 to 10)
(If p1=ControlGroup)
Program pattern number (1 to 99)
(If p1=ProgramSelect)
p3
Batch group number (All, 1 to the number
used)
p3 is valid when the multi batch function (/
BT) is enabled.
Query
SHomeKind?
Example Set the standard screen to trend of display
group 1.
SHomeKind,Trend,1
Description
• Report is an option (/MT).
• Modbus-M and Modbus-C are an option (/MC).
• Watt is an option (/E2).
• CustomDisplay is an option (/CG).
• Multi is a GX20/GP20 display.
• p3 is valid when the multi batch function (/BT) is
enabled.
• When the multi batch function (/BT) is not available,
p3 is fixed to 1.
• p1 cannot be set to BatchOverview when p3 is 1 to
12.
P1 cannot be set to Trend, Digital, Bar, Alarm,
Message, Memory, or Multi when p3 = All.
• p3 cannot be set to All when p1 is set to Trend, Digital,
Bar, Alarm, Message, Memory, or Multi.
p3 cannot be set to 1 to 12 when p1 is set to
BatchOverview.
•
ControlGroup, ControlSummary,
ControlAlarmSummary, ControlOverview, and Tuning
are valid when the PID control module is installed.
• ProgramSelect and ProgramRun are options (/PG).
SFavoriteMonitor
Favorite Screen Display Information
[GX/GP]
Sets the favorite screen display information.
Syntax
SFavoriteMonitor,p1,p2,p3
p1
Favorites number (1 to 20)
p2
Information type (see the table of the
SMonitor command)
p3
Status (see the table of the SMonitor
command)
Query
SFavoriteMonitor[,p1[,p2]]?
Example Set the trend display to all-channel display.
SFavoriteMonitor,1,Trend,All
2.4 Setting Commands
