Installation of the Spare transmitter
Quick Reference Instruction Manual for Spare
Transmitter replacement
IM01U10A01-00EN-R, 1
st
edition, 2019-12-09
35 / 76
5. Remove the display from housing by pulling forward.
6. Rotate display and push back into housing in the orientation desired.
NOTICE
The display can be removed and replaced by loosening the connector.
