YOKOGAWA ZR402G User Manual

<9. Calibration>
9-8
IM 11M12A01-04E 11th Edition : Jul. 19, 2017-00
• When the calibration mode is in automatic:
In addition to the above hold (output stabilization) time and calibration time, set the interval,
start date, and start time.
Interval means the calibration intervals ranging from 000 days, 00 hours to 255 days, 23
hours.
Set the rst calibration day and the start-calibration time to the start date and start time
respectively. After the rst calibration is carried out, the next calibration will be executed
according to the preset calibration intervals.
n Setting
When setting calibration timing requirements, bear the following precautions in mind:
NOTE
(1) If the calibration interval is shorter than the sum of hold (output stabilization) time plus
calibration time, the second calibration start time will conict with the rst calibration. In such
a case, the second calibration will not be conducted. (When both zero and span calibrations
are to be performed, the calibration time is double that required for a single (zero or span)
calibration.)
(2) For the same reason, if the calibration start time conicts with manual calibration or semi-
automatic calibration, the current calibration will not be conducted.
(3) If the calibration time conicts with maintenance service operation, calibration will start after
completing the maintenance service operation (see Section 8.2.1, earlier in this manual).
(4) If 000 days, 00 hours are set for the calibration intervals, only the rst calibration will be
conducted; a second or later calibration will not be conducted.
(5) If a past date is set to the calibration start day, no calibration will be conducted.
Table 9.1 Parameter Codes for Calibration Setting
Set Item
Parameter
code
Set value
Engineering
unit
Zero gas concentration B01 Set Zero gas concentration %O
2
Span gas concentration B02 Set Span gas concentration %O
2
Calibration mode B03 0 Manual calibration
1 Semi-automatic and manual
2 Automatic, semi-automatic, and manual
Hold (Output stabilization) time B04 0 minutes 0 seconds to 60 minutes 59 seconds MM.SS
Calibration time B05 0 minutes 0 seconds to 60 minutes 59 seconds MM.SS
Calibration interval B06 0 days 0 hours to 255 days 23 hours Date and time
Start date and time B07 Date and time of rst calibration YY.MM.
DD.HH.MM
Calibration procedure B08 0 Zero and span
1 Span only
2 Zero only
n Default Values
When the analyzer is delivered, or if data are initialized, the calibration settings are by default, as
shown in Table 9.2.
