YOKOGAWA ZR402G User Manual

<7. Startup>
7-10
IM 11M12A01-04E
Table 7.5 Minimum and Maximum Value Setting Procedure
Switch operation Display Description
> ∧
ENT
A01
Display after the password has been entered.
> ∧
ENT
C01
Set the oxygen concentration at 4 mA. Change the parameter code to
C11. Touch the [∧] key to switch to Group C.
> ∧
ENT
C01
Touch the [>] key to move the position of the digit that is ashing to the
right.
> ∧
ENT
C11
Touch the [∧] key to enter the numeric value 1.
> ∧
ENT
000
Touch the [ENT] key to display the current set value (0% O2 has been
set).
> ∧
ENT
000
Touch the [>] key to move the position of the digit that is ashing to the
right.
> ∧
ENT
010
Touch the [∧] key to change the numeric value to 1.
> ∧
ENT
010
If you touch the [ENT] key, all the digits ash.
> ∧
ENT
010
Touch the [ENT] key again to stop the ashing.
> ∧
ENT
C11
Touch the [ENT] key once again, and the display will switch to the
parameter code selection display.
> ∧
ENT
C11
Set the oxygen concentration at 20 mA. Touch the [>] key to move the
position of the digit that is ashing to the right.
> ∧
ENT
C12
Touch the [∧] key to enter the numeric value 2.
> ∧
ENT
025
Touch the [ENT] key to display the current set value.
> ∧
ENT
025
Touch the [>] key to move the position of the digit that is ashing to the
right.
> ∧
ENT
020
Touch the [∧] key to change the numeric value to 0. The numeric value
will change from 5 to 6 ... to 9 and back to 0.
> ∧
ENT
020
If you touch the [ENT] key, all the digits ash.
> ∧
ENT
020
Touch the [ENT] key again to stop the ashing.
> ∧
ENT
C12
Touch the [ENT] key once again to switch to the parameter code selection
display.
> ∧
ENT Basic
panel
display
Touch the [>] key together with the [ENT] key to return to the basic panel
display. (This is not required if you proceed to make another setting.)
(The displayed numeric characters indicate the measurement gas
concentration.)
The symbol [ ] indicates that the key is being touched. Light characters indicates that the digits are ashing.
11th Edition : Jul. 19, 2017-00
