<7. Startup>
7-17
IM 11M12A01-04E
(3) Oxygen concentration in span gas
Enter the span gas oxygen concentration for calibration. If instrument air is used, enter 21
vol % O
2
. When using the ZO21S Standard Gas Unit (for use of the atmospheric air as a
span gas), use a hand-held oxygen analyzer to measure the actual oxygen concentration,
and then enter it.
CAUTION
If instrument air is used for the span gas, dehumidify the air to a dew point of -20°C and remove
any oil mist or dust.
Incomplete dehumidifying or unclean air will have an adverse effect on the measurement
accuracy.
Table 7.14 Calibration Parameter Codes
Set item Parameter code Set value
Calibration mode B03 0 Manual calibration
1 Semi-automatic calibration
2 Automatic calibration
Zero gas oxygen concentration B01 Enter oxygen concentration.
Span gas oxygen concentration B02 Enter oxygen concentration.
11th Edition : Jul. 19, 2017-00
