Table 7.15 Calibration Setup Procedure
Switch operation Display Description
> ∧
ENT
A01
Display after the password has been entered.
> ∧
ENT
b01
Set the zero gas concentration. Switch the parameter code to
B01.
Here, set 0.98%.
> ∧
ENT
001.00
%
Touch the [ENT] key to display the currently set value.
> ∧
ENT
001.00
%
Touch the [>] key to move the position of the digit that is ashing
to 1.
> ∧
ENT
000.00
%
Touch the [∧] key to change to 0.
> ∧
ENT
000.00
%
Touch the [>] key to move the position of the digit that is ashing
to the right one digit.
> ∧
ENT
000.90
%
Touch the [∧] key to change the numeric value to 9.
> ∧
ENT
000.90
%
Touch the [>] key to move the position of the digit that is ashing
to the right one digit.
> ∧
ENT
000.98
%
Touch the [∧] key to change the numeric value to 8.
> ∧
ENT
000.98
%
Touch the [ENT] key to have all the digits ash.
> ∧
ENT
000.98
%
Touch the [ENT] key again to stop the ashing.
> ∧
ENT
b01
Touch the [ENT] key once again to switch to the parameter code
selection display.
Set the span gas concentration by above procedure, set 21 %.
> ∧
ENT b03
Next, set the calibration mode. Switch the parameter code to B03.
> ∧
ENT
0
Touch the [ENT] key to display the currently set value.
If it is 0, you can leave it as is. If it is other than 0, change it to 0
(zero).
> ∧
ENT
0
Touch the [ENT] key. The numeric value will ash.
> ∧
ENT
0
Touch the [ENT] key again to stop the ashing.
> ∧
ENT
b03
Touch the [ENT] key once again to switch to the parameter code
selection display.
> ∧
ENT Basic panel
display
Touch the [>] key together with the [ENT] key to return to the basic
panel display. (This is not required if you proceed to make another
setting.)
(The displayed numeric characters indicate the measurement gas
concentration.)
The symbol [ ] indicates that the key is being touched. Light characters indicates that the digits are ashing.
