York YZ MODEL A - FIGURE 43 - Right Side of Drive Cabinet Model PYT780

JOHNSON CONTROLS
113
SECTION 4 - VSD OPERATION
FORM 161.01-OM1
ISSUE DATE: 6/8/2018
4
LD26710
CD
POWER
UNIT
A
B
E
F
A
300VDC Magnetic
Bearing Power Supply
B Main UPS
C
UPS Battery
(Behind Panel)
D Filter Power Unit
E Cooling Coil
F Cooling Fan
Inverter
Rectifier
FIGURE 43 - RIGHT SIDE OF DRIVE CABINET MODEL PYT780
