SECTION 3 - OPTIVIEW™ CONTROL CENTER FUNCTIONS AND NAVIGATION
FORM 161.01-OM1
ISSUE DATE: 6/8/2018
3
LANGUAGES
The screens can be displayed in various languages.
Language selection is done on the user screen. The de-
sired language is selected from those available. Eng-
lish, French, German, Hungarian, Italian, Japanese,
Korean, Portuguese, Simplified Chinese, Traditional
Chinese, Russian and Turkish. English is the default
language. If a language other than English is being dis-
played, an English speaking person can navigate to the
USER screen (using the preceding Navigation chart)
and select English.
ANALOG INPUT RANGES
The following table indicates the valid display range
for each of the analog input values. In the event that the
input sensor is reading a value outside of these ranges,
the < or > symbols will be displayed beside the mini-
mum or maximum value, respectively.
TABLE 4 - ANALOG INPUT RANGES
ANALOG INPUT
ENGLISH RANGE METRIC RANGE
LOW HIGH UNITS LOW HIGH UNITS
Leaving Chilled Liquid Temperature 0.0 133.9 °F -17.7 56.6 °C
Return Chilled Liquid Temperature 0.0 133.9 °F -17.7 56.5 °C
Leaving Condenser Liquid Temperature -20.0 180.0 °F -28.8 82.2 °C
Return Condenser Liquid Temperature -20.0 180.0 °F -28.8 82.2 °C
Evaporator Refrigerant Temperature (Optional) 0.0 133.9 °F -17.7 56.6 °C
Discharge Temperature 20.0 226.3 °F -6.67 107.9 °C
Condenser Pressure 0.0 80.0 PSIA 0.0 552 KPA
Condenser Temperature* -99.7 163.3 °F -73.2 72.9 °C
Evaporator Pressure 0.0 30 PSIA 0 206.8 KPA
Evaporator Temperature* -99.7 101.7 °F 73.2 38.7 °C
Refrigerant Level 0.0 100.0 % 0.0 100.0 %
Drop Leg Refrigerant Temperature -20.0 180.0 °F -28.8 82.2 °C
Motor Housing Temperature 10.0 270.0 °F 12.2 132.2 °C
*Saturation temperatures are calculated values. They will display XXX if the pressure used for the calculation is out of range.
