York YZ MODEL A - FIGURE 45 - Right Side of Drive Cabinet Model PYT1020

JOHNSON CONTROLS
115
SECTION 4 - VSD OPERATION
FORM 161.01-OM1
ISSUE DATE: 6/8/2018
4
LD26717
D
E
A
B
F
G
C
A
300VDC Magnetic
Bearing Power Supply
B Main UPS
C Bus Capacitors
D
UPS Battery
(Behind Panel)
E Filter Power Unit
F Cooling Coil
G Cooling Fan
FIGURE 45 - RIGHT SIDE OF DRIVE CABINET MODEL PYT1020
