JOHNSON CONTROLS
37
SECTION 3 - OPTIVIEW™ CONTROL CENTER FUNCTIONS AND NAVIGATION
FORM 161.01-OM1
ISSUE DATE: 6/8/2018
3
DISPLAY ONLY FIELDS
FIELD/LED NAME DESCRIPTION
Active Level Setpoint Displays the setpoint to which the refrigerant level is being controlled.
Level Control Valve Command
Displays the position command to the level control valve in percent of travel with
0% full closed to 100% full open.
NAVIGATION
NAVIGATION
BUTTON DESCRIPTION
Home Causes an instant return to the Home Screen.
Purge Navigates to the Purge Screen where the Operator can view the purge param-
eters and select Standard or Enhanced Purge mode of operation.
Head Pressure Control Navigates to the Head Pressure Control Screen where the Operator can view
and adjust some of the Head Pressure Control parameters.
