York YZ MODEL A - Page 71

JOHNSON CONTROLS
71
SECTION 3 - OPTIVIEW™ CONTROL CENTER FUNCTIONS AND NAVIGATION
FORM 161.01-OM1
ISSUE DATE: 6/8/2018
3
DISPLAY ONLY FIELDS
FIELD/LED NAME DESCRIPTION
Volts Factory dened motor line Voltage.
Phases Factory dened number of line Phases.
Frequency Factory dened line Frequency.
LRA Factory dened motor Locked Rotor Amps.
Full Load Amps Factory dened motor Full Load Amps.
Inrush Amps Factory dened motor Inrush Amps
Refrigerant Factory dened type of Refrigerant.
Capacity Factory dened chiller Tonnage.
Gear Code Factory dened compressor Gear Code.
Liquid Type Factory dened Liquid Type Water or Brine.
Brine Percent Factory dened Percent Brine solution if applicable.
VSD/SSS/EM Factory dened type of Starter. (VSD).
Kilowatts Input Factory dened design Input KW.
PROGRAMMABLE
PROGRAMMABLE
BUTTON ACCESS LEVEL DESCRIPTION
Print Operator This generates a listing of the Sales Order data.
NAVIGATION
NAVIGATION
BUTTON DESCRIPTION
Home Causes an instant return to the Home Screen.
Setup Return to the previous Setup Screen.
