York YZ MODEL A - Page 81

JOHNSON CONTROLS
81
SECTION 3 - OPTIVIEW™ CONTROL CENTER FUNCTIONS AND NAVIGATION
FORM 161.01-OM1
ISSUE DATE: 6/8/2018
3
PROGRAMMABLE
PROGRAMMABLE
BUTTON ACCESS LEVEL DESCRIPTION
Start Operator
Pressing this key clears the graph, starts a new graph, sets the time of day
to the present clock time and begins the trending. This key is only available if
trending is stopped. If the selected Chart Type is TRIGGERED and TRIGGER
ACTION is set to START, data collection will not begin until the Triggers have
been satised and any selected TRIGGER DELAY has elapsed. Otherwise, data
collection will begin immediately.
Stop Operator
Pressing this key stops the trending. The trend data is frozen on the display until
another graph is started with the START key. The STOP key is only available if
trending is running.
Print Operator
Allows the data on the trend screen to be printed in tabular format. If set to EX-
ISTING, a snapshot of the data presently on the screen is sent to the printer. If
set to NEW, all data collected after pressing this key will be sent to the printer as
it is collected. If set to DISABLED, no data is sent to the printer.
Data Select Operator
Allows the user to display all trended data points simultaneously or select a
single trended data point for display, hiding the other data points. Selections are
ALL DATA or DATA POINT X (1-6).
Y-Axis Operator
This key toggles the Y-Axis labels of the graph. Each key press changes the
label to another of the selected parameters.
X-Axis Operator
This key toggles the X-Axis labels of the graph. Each key press alternates
the scaling between time of day and elapsed time. The Time of Day scal-
ing is in 24-hour format. The Elapsed Time scaling is the time elapsed
since the START key was pressed, starting the trending.
NAVIGATION
NAVIGATION
BUTTON ACCESS LEVEL DESCRIPTION
Home View Causes an instant return to the Home Screen.
History View Causes an instant return to the History Screen.
Trend Setup Operator
Only displayed if the trending is stopped. Causes a jump to a subscreen for
conguring the trending display.
DISPLAY ONLY FIELDS
This screen allows the user to view the graphical trend-
ing of the selected parameters and is also a gateway to
the graph setup screens.
A red screen displaying TREND MAX
MUST BE > TREND MIN will appear
if the Y-Axis minimum has been pro-
grammed to a value that is greater than
the Y-Axis maximum for any parameter.
If this appears, proceed to the Trend Setup
Screen to change the values.
