Data Capture
117
Pairing a DS3678 Scanner
To connect an DS3678 scanner to the tablet, use one of the following methods:
• Simple Serial Interface (SSI) mode
• Bluetooth Human Interface Device (HID) mode.
Pairing a DS3678 Scanner Using Simple Serial Interface (SSI)
To pair the DS3678 scanner with the tablet using SSI:
1. Ensure that the scanner is in SSI mode.
2. Ensure that the two devices are within 10 meters (32.8 feet) of one another.
3. On the tablet, swipe up from the bottom of the Home screen and touch the Bluetooth Pairing Utility.
Figure 92 Bluetooth Pairing Utility
4. Use the scanner to scan the barcode on the screen.
The scanner emits a high/low/high/low beeps. The Scan LED flashes green indicating that the scanner is
attempting to establish connection with the tablet. When connection is established, the Scan LED turns off and
the scanner emits one string of low/high beeps.
5. On the tablet, touch .
