Wireless
94
Figure 72 WLAN 802.11 EAP Network Security Dialog Box
8. If the network security is WEP or WPA/WPS2 PSK, enter the required password and then touch Connect.
9. If the network security is 802.1x EAP, follow these steps:
• Touch the EAP method drop-down list and select PEAP, TLS, TTLS, PWD, or LEAP.
• Touch the Phase 2 authentication drop-down list and select an authentication method.
• If required, touch CA certificate and select a Certification Authority (CA) certificate. Note: Certificates are
installed using the Security settings.
• If required, touch User certificate and select a user certificate.
Note: User certificates are installed using the location & security settings.
• If required, in the Identity text box, enter the username credentials.
• If you like, in the Anonymous identity text box, enter an anonymous identity username.
• If required, in the Password text box, enter the password for the given identity.
NOTE: By default, the network Proxy is set to None and the IP setting is set to DHCP. See Configuring for a Proxy
Server
on page 95 for setting connection to a proxy server. See Configuring the Device to Use a Static IP Address
on page 96 for setting the device to use a static IP address.
10.
Touch Connect.
11. Touch .
Manually Adding a Wi-Fi Network
Manually add a Wi-Fi network if the network does not broadcast its name (SSID) or to add a Wi-Fi network when
out of range.
1. Swipe down from the status bar and then touch the Settings icon.
2. Touch Network & Internet > Wi-Fi.
3. Slide the Wi-Fi switch to the On position.
