Getting Started
17
Figure 2 XSLATE Back Side
Table 2 XSLATE Back Features
Item Description
1 The pen holder holds the short, capacitive pen when not in use.
2 The battery latch releases the battery when you slide the latch to the left.
3 This light is a flash for the rear camera and can be used as a flashlight.
4 The rear 13-megapixel camera has Full HD resolution.
5 The Kensington lock slot is a metal-reinforced hole for use with a cable and lock to secure the tablet.
6 Near Field Communication (NFC) allows devices to exchange information by placing them next to
one another.
7 The expansion port cover is removed when connecting certain optional accessories to the tablet.
8 This speaker provides sound when no headset or external speakers are in use.
9 The battery powers the tablet when it is not plugged in or docked.
2 3 4 5
6
1
7
89
