Zebra TC20 Series User Manual

Accessories
124
Figure 98 Charging with USB Cable
Power Pack Charging
The Power Pack Charging LEDs indicate the status of charging. See Table 18 on page 124 for charging status.
The power pack charges from fully depleted to 90% in approximately four hours and from fully depleted to
100% in approximately five hours.
Figure 99 Power Pack LEDs
LED 1LED 2LED 3LED 4LED Button
Table 18 LED Charging Indicators
LED State
LED 1 LED 2 LED 3 LED 4 Indication
Not charging.
Flashing
Charge level is between 0% and 33%.
Solid Flashing
Charge level is between 33% and 66%.

Zebra TC20 Series Specifications

General

RAM	2 GB
Operating Temperature	-10°C to 50°C
Display	4.3 in. WVGA (480 x 800)
Storage	16 GB
Camera	8 MP rear camera
Battery	3000 mAh
Connectivity	Wi-Fi 802.11 a/b/g/n/ac, Bluetooth 4.2, NFC
Dimensions	134 mm x 73.1 mm x 16 mm
Weight	195 g
Expansion Slot	MicroSD up to 128 GB
Scanning	1D/2D imager
Drop Specification	1.2 m (4 ft) to concrete
