Accessories
138
Hand Strap
NOTE: There are two different hand straps for the device and the TC20K. The TC20K hand strap is longer. TC20 hand strap
installation is shown below. TC20K hand strap installation is the same.
The hand strap provides securing when holding the device.
To install the hand strap on the device:
1. Feed the top end of the hand strap through the slot at the top of the device.
Figure 121 Insert Hand Strap Through Top Mounting Point
2. Pull the end through the slot.
Figure 122 Feed End Through Slot
3. Insert the end of the hand strap into the slot on the hand strap.
4. Pull the end until the notch sits into the slot.
5. Feed the other end of the hand strap through the slot at the bottom of the device.
Figure 123 Insert Hand Strap Through Bottom Mounting Point
6. Pull the end through the slot.
7. Press the hook material against the loop material.
