Zebra TC20 Series User Manual

Maintenance and Troubleshooting
147
1. Remove the DC power cable from the cradle.
2. Dip the cotton portion of the cotton-tipped applicator in isopropyl alcohol.
3. Rub the cotton portion of the cotton-tipped applicator along the pins of the connector. Slowly move the
applicator back-and-forth from one side of the connector to the other. Do not leave any cotton residue on
the connector.
4. All sides of the connector should also be rubbed with the cotton-tipped applicator.
CAUTION: Do not point nozzle at yourself and others, ensure the nozzle or tube is pointed away from your face.
5. Spray compressed air in the connector area by pointing the tube/nozzle about ½ inch away from the
surface.
6. Remove any lint left by the cotton-tipped applicator.
7. If grease and other dirt can be found on other areas of the cradle, use a lint-free cloth and alcohol to
remove.
8. Allow at least 10 to 30 minutes (depending on ambient temperature and humidity) for the alcohol to air dry
before applying power to cradle.
If the temperature is low and humidity is high, longer drying time is required. Warm temperature and dry
humidity requires less drying time.
Troubleshooting
The following tables provides typical problems that might arise and the solution for correcting the problem.
TC20
Table 20 Troubleshooting the TC20
Problem Cause Solution
When pressing the
power button the
TC20 does not turn
on.
Battery not charged. Charge the battery in the TC20.
System crash. Perform a reset.
When pressing the
power button the
TC20 does not turn
on but two LEDs
blink.
Battery charge is at a
level where data is
maintained but battery
should be re-charged.
Charge the battery in the TC20.
Battery did not
charge.
Battery failed. Contact system administrator.
TC20 removed from
cradle while battery was
charging.
Insert TC20 in cradle. See Charging the Battery on page
18.
Extreme battery
temperature.
Battery does not charge if ambient temperature is below
0°C (32°F) or above 40°C (104°F).
Cannot see
characters on display.
TC20 not powered on. Press the Power button.
