Operations
Load Media
42
79695L-002 Rev. A Z Series
®
/RZ™ Series User Guide 6/6/08
3. Insert media into the printer. Follow the instructions for roll or fanfold media, as
appropriate.
Roll Media
Fanfold Media
a. Remove and discard any tags or
labels that are dirty or that are held
by adhesives or tape.
a. Flip down the media supply guide.
b. Flip down the media supply guide. b. Feed the media through the rear or
bottom access slot.
Rear Feed
Bottom Feed
c. Place the roll of media on the media
supply hanger. Push the roll as far
back as it will go.
d. Flip up the media supply guide. c. Drape the media over the media
supply hanger.
