Zeiss Axio Observer 5 - Configuring of 5, 5 Materials Stand

OPERATION
Axio Observer Basic settings on Axio Observer 5, 5 materials stand ZEISS
12/2016 431004-7244-001 107
5.7.1 Configuring of 5, 5 materials stand
Set Objective
Set ReflModule
Set RL Slider
Set Lamp Output
Set Ext. Shutter
Set Light Manager
Set Dazzle Protection
FL filter sets
Fluorochromes
Contrast
Beam splitters
Other filters
None
List of objectives
FL attenuator
Aperture
HAL TL
LED TL
HAL RL
LED RL
None
RL
TL
None
Off
Smart
Classic
RL + TL
RL
TL
Off
List of FL filter sets
List of fluorocromes
List of contrast modules
List of beam splitters
List of other filters
Fig. 86 Structure of configuration menu
Pressing and holding down the LM set button for > 2 s will activate configuration mode with the
following menu options:
− Set Objective (nosepiece)
− Set ReflModule (reflector turret)
− Set RL Slider (A) (slider for the reflected light illuminator aperture)
− Set Lamp Output (illuminator power)
− Set Ext. Shutter
− Set Light Manager
− Set Dazzle Protection
