OPERATION
ZEISS Operating and function controls - description Axio Observer
96 431004-7244-001 12/2016
Automatic component recognition (ACR) on the 5, 5 materials and 7, 7 materials stands
Automatic component recognition (ACR) means automatic recognition of objectives and reflector
modules on the Axio Observer.
When replacing an objective (7, 7 materials stands only) or a reflector module (5, 5 materials and 7,
7 materials stands), the system will register the replaced component. This is important for operator
comfort and safety: It helps avoid operating errors and the need for time-consuming programming.
The differences between automatic component recognition for the nosepiece and for the reflector turret
are explained below.
−
Nosepiece (optional, only 7, 7 materials stand)
Automatic component recognition for the nosepiece is initiated by pressing the appropriate button on
the Settings/Components/Objectives screen on the TFT display (see section 5.11.9.1)
For the 7 stand the nosepiece is an optional component (see also section 3.4).
This includes:
− Standard mot. (without ACR)
− mot. with ACR
− Definite Focus.2 (mot. with ACR)
The 7 materials stand is always equipped with the ACR nosepiece (part of delivery scope).
For ACR functionality with objectives, these must be additionally equipped with an appropriate
"ACR objective ring".
ACR with reflector modules requires a reflector turret mot. ACR. The reflector modules must
also be marked with “ACR”.
− Reflector turret (optional, 5, 5 materials, 7, 7 materials stands)
Automatic component recognition for the reflector turret is initiated automatically as soon as the ACR
reflector turret cover is closed
