Zetor PROXIMA HS Series User Manual

Maximum permissible vertical static load of hitches for trailers and semi-trailers
The maximum weight of an aggregated braked trailer or semi-trailer must not exceed the value
specified on the data plate of the tractor and the value specified in the technical certificate of the
tractor. The maximum permissible speed of the set results from the maximum permissible speed of
the slower vehicle in the set.
Hitch of class C: max. weight of the trailer 6,000kg.
Hitch of class D2: max. weight of the trailer 14,000kg.
Hitch of class D3: max. weight of the trailer 20,000kg.
Hitch type Permissible
vertical static
load
Hitch
pin Ø
Hitch type Permissible
vertical static
load
Hitch
pin Ø
2 000 kg
31 mm
2 000 kg
38 mm
Hitch class D2 Hitch class C
2 000 kg
43 mm
2 000 kg
28 mm
The maximum weight of an aggregated braked trailer or semi-trailer must not exceed the value
specified on the data plate of the tractor and the value specified in the technical certificate of the
traktor. The maximum permissible speed of the set results from the maximum permissible speed of
the slower vehicle in the set.
Hitch type Permissible
vertical static
load
Hitch pin
(ball) Ø
Hitch type Permissible
vertical static
load
Hitch
pin
(ball) Ø
736 kg
31 mm
2 000 kg
80 mm
2 000 kg
47 mm
1 200 kg
31 mm
Fixed pin
2,000 kg
44,5 mm
TRANSPORT USE
105
