Zetor PROXIMA HS Series User Manual

Main tractor's parameters (mm)
Note
Outline length with hitches with the front
three-point hitch lowered
4708 without ballast weights
Outline length with hitches without the
front three-point hitch
4067 without ballast weights
Width over the rear fenders 1890
Height to the exhaust outlet 2694 - 2780
depending on tyre
dimensions
Tractor height to the upper cab edge 2639 - 2725
depending on tyre
dimensions
Inner height under the front axle support 468 - 508
depending on tyre
dimensions
Height of the mouth of the stage hitch in
the top position (mouth centre)
1012 - 1098
depending on tyre
dimensions
Height of the rear PTO 760 - 845
depending on tyre
dimensions
Height of the front PTO 636 - 806
depending on tyre
dimensions
Wheel base 2442
MAIN TECHNICAL PARAMETERS
191
