Zetor PROXIMA HS Series User Manual

Change of the load capacity of the rear tyres (%)
Permitted combinations of wheels for tractors
Travelling speed (km/h) diagonal radial
8 + 40 + 50
20 + 20 + 23
30 0 + 7
40 - 20 0
Performance on rear PTO shaft
Lifting force of the three-point hitch
Front wheels Rear wheels
Tyre size equivalent Tyre size equivalent
11,2-24 11,2R24 13,6-36
16,9-30 16,9R30
480/70R30
12,4-24 12,4R24
360/70R24
18,4-30 18,4 R30
520/70R30
16,9-34 16,9R34
480/70R34
13,6-36
13,6-24 13,6R24
380/70R24
16,9-34 16,9R34
480/70R34
18,4-34 18,4R34
520/70R34
600/65R34
Tractor type
Proxima HS
100
Proxima HS
110
Proxima HS
120
PTO power (kW ± 2%)
- at the nominal engine speed and engaged 1000 rpm of
the PTO
Engine in the running-in stage (until 100 hours) 55 62,5 69,5
Engine after the running-in stage (from 100 hours on) 58 65,5 73
Tractor type Proxima HS 100 Proxima HS 110 Proxima HS 120
Lifting force at the end of the lower draw-bars of the
rear three-point hitch in the whole lifting range at
the maximum usable pressure with 2 outer
cylinders
- cylinder 75 mm in diameter (kN)
38
Lifting force at the end of the lower draw-bars of the
front three-point hitch in the whole lifting range at
the maximum usable pressure (kN)
23
MAIN TECHNICAL PARAMETERS
197
