Free (floating) positio
Adjustable stop
Three-point hitch lowering speed control
Hydraulic system sensitivity control
Free (floating) position makes it possible to work with tools
with a support wheel. In this position, the arms of the rear
three-point hitch are loose.
Move lever (2) to the front position (a).
The position of lever (1) makes no difference.
P+11N004
Under default settings, it is recommended to set the
adjustable stop (1) to a position on the edge between
floating position and the beginning of the range of lifting of
the rear three-point hitch (b). After pushing the lever
towards you, the lever can be moved over the adjustable
stop.
P+11N009
Three-point hitch lowering speed control (3) selects the
speed of lowering the arms of the rear three-point hitch.
Turning the knob in (b) direction reduces the lowering
speed of the arms of the rear three-point hitch, turning it in
(a) direction increases the speed. If the knob is turned in
(b) direction to its stop point, the arms of the rear three-
point hitch cannot be lowered.
P+11N006
Hydraulic system sensitivity control (4) adjusts the
sensitivity of the hydraulics in power or mixed regulation.
Turning the knob in (a) direction increases sensitivity,
turning it in (b) direction decreases sensitivity.
E408
