3.5 Transport, storage
Attention!
Observe the weight specications (see rating plate) and the permissible carrying loads of the means
of transport.
Wear safety clothing / shoes and cut-resistant safety gloves when handling!
Do not transport the fan by the connecting cable!
Avoid shocks and impacts to the device during the transport.
Avoid extreme humidity, heat or exposure to cold (see technical data).
Watch out for possible damage to the packaging or fan.
Secure pallets during transport.
Do not stack pallets.
Only handle with suitable hoisting gear.
Position the lifting beam transversely to the motor axis. Pay attention to adequate width of the lifting
beam.
Never stand underneath the suspended fan because defective transport equipment could cause
death.
Store the fan / motor in the original packaging in a dry area protected from the weather and protect
it from dirt and weather until nal installation.
Avoid prolonged storage; we recommend a maximum of one year (consult the manufacturer before
starting if stored for longer).
Inspect the bearing for proper operation prior to installation.
Recommendation: Turn the impeller evenly by hand to avoid jamming and damaging the
bearing.
Transport the fan(s) either in the original packaging or, in the case of larger fans, on the dedicated
transportation xtures.
axial fans: holes drilled in support arms, wall ring plates and motor block
centrifugal fans depending on type: holes drilled in the housing ange, motor block, fastening
brackets and support plates,
Radial impellers, fans with scroll RG.., RD.. or built-in fans type ER../GR.., WR.. are generally
delivered on europallets, and can be transported using lift trucks.
Design RG.. / RD.. / ER.. / GR../ WR../HR.. : Fan unit may only be lifted and transported when
using a suitable hoisting device (load spreader). Ensure sufcient cable or chain length.
Design WR: lifting several fan units mounted on top of one another or next one other is not
permitted!
Design FV.. / DN.. : The fan must be fastened to 4 points during transport so the anges do not
warp.
3.6 Disposal / recycling
Disposal must be carried out professionally and in an environmentally friendly way in accordance with
the respective national legal stipulations.
" Separate the materials by type and in an environmentally-friendly way.
" If necessary, commission a specialist company with the waste disposal.
Assembly instructions ECblue Product overview
