2.3 Explanations of symbols
Safety instructions are highlighted with warning triangles and are depicted according to the degree of
hazard as follows.
Attention!
General hazardous area. Death or severe injury or signicant property damage can occur if the
corresponding precautions are not taken!
Danger due to electric current
Danger by dangerous, electric voltage! Death or severe injury can occur if the corresponding
precautions are not taken!
Info
Important additional information and advice for user.
2.4 Product safety
The device conforms to the state of the art at the time of delivery and is fundamentally considered to
be reliable. The device and its accessories must only be used in a awless condition and installed and
operated in compliance with the assembly instructions and/or operating instructions. Operating out-
side the device's technical specications (see name plate and attachment / technical data) can lead to
a defect in the device and additional damage!
Info
A separate fault and performance monitoring-system with an alarm signal function is necessary in
order to prevent personal injuries and material damages during malfunctions and in case the device
fails. Substitute operation must be taken into consideration! The design and installation of the system
must comply with local regulations and directives.
2.5 Requirements placed on the personnel / due diligence
Persons entrusted with the planning, installation, commissioning and maintenance and servicing in
connection with the frequency inverter must have the corresponding qualications and skills for these
jobs.
In addition, they must be knowledgeable about the safety regulations, EU/EC directives, rules for the
prevention of accidents and the corresponding national as well as regional and in-house regulations.
Personnel to be trained or instructed and apprentices are only permitted to work on the device under
the supervision of an experienced person. This also applies to personnel undergoing general training.
Comply with the legal minimum age.
2.6 Work on the device
Information
Mounting, electrical connection, and start-up operation may only be carried out by an electrical
specialist in accordance with electrotechnical regulations (e.g. EN 50110 or EN 60204)!
Danger due to electric current
It is generally forbidden to carry out work on electrical live parts!
Only remove the lid from the terminal compartment (available depending on the model) with the line
voltage switched off!
Opening of the base lid is prohibited. Loosening the safety screws will void the guarantee!
Protection class of the device when complete open is IP00! It is possible to touch hazardous
voltages directly.
Through use of capacitors, danger of death exists even after switching off the device!
The rotor is not protected against indirect contact neither by supplementary or reinforced insulation
nor by connection to safety-earth in accordance with EN 60204-1, therefore the motor/fan must be
installed so that it is not touchable.
When the motor runs independently due to air owing through or if it continues to run down after
being turned off, dangerous voltages of over 50 V can arise on the motor internal connections
through operation of the generator.
The safe isolation from the supply must be checked using a two-pole voltage detector.
Assembly instructions ECblue Safety instructions
L-BAL-F055D-GB 2021/51 Index 006 Part.-No.
7/56
