zipwake S Series - Offsetting the Automatic Pitch

ZIPWAKE DYNAMIC TRIM CONTROL SYSTEM - FOR INTEGRATION16
8.4 OFFSETTING THE AUTOMATIC PITCH
Even if Auto Pitch Control is activated, you can manually oset the automatic pitch
setting to compensate for dierent sea and load conditions.
1. Tap the vertical bar (A) to open the
pitch controls.
NOTE!
Saving a preferred trim setting in this manner, at a few dierent boat speeds, is a very
quick way to build the optimum pitch curve for your boat with its specific load.
Details of the curve can be viewed and adjusted from the menu page (chapter 8.5).
2. To trim the bow down, tap/hold bow
down (B) to increase pitch oset.
To trim the bow up, tap/hold bow up (C)
to decrease pitch oset.
3. If an adjustment results in a better
running trim, you can save it by holding
the pitch oset value indication (D) until
it disappears.
A
B
D
D
C
Local adjustment
around current speed
