8.5 EDIT THE AUTO PITCH CONTROL CURVE
The Auto Pitch Control Curve tells the system how much the interceptors should be
extended at each speed, thereby adjusting the boat’s pitch angle as a function of speed.
When starting the system the first time (chapter 5), a default curve is calculated based
on your boat data (length, beam, weight). The Auto Pitch Control Curve can be viewed
and fine-tuned from the menu page.
NOTE!
Tap RESET (C) to reset the Auto Pitch Control Curve to the default settings for the
current boat data.
1. Tap to open the System Menu.
2. Tap AUTO Setup.
3. Tap OPEN or on the pitch curve to
enable pitch curve adjustment.
4. Adjust the pitch curve bars (A) by touch
and drag or use the buttons (B) to
adjust the extension for a desired speed.
5. Repeat step 4 to adjust more than one
setting.
6. Tap SAVE to update the curve.
A
B
C
