61
4. Enter the [12-lead] interface and select the lead system and the single-ratio lead label;
5. According to your own needs, set other parameters, and exit the [Standard ECG] interface
after the setting is completed.
6. Click the “ ” button on the panel to print the automatic mode ECG report.
When the ECG signal is just connected or the device receives the overload
noise, the waveform will be disordered, the baseline drift is serious, and the
signal waveform amplitude may exceed the maximum display width. At this
time, wait for the device connection and the patient as well as the waveform to
stabilize. Then start measuring and recording.
When the ECG is overloaded or any part of the amplifier is saturated, the ECG
machine is in an abnormal working state. At this time, the interface only
displays the baseline. In order to obtain accurate measurement results, wait
for the device connection and the patient as well as the waveform to stabilize.
Then start measuring and recording.
If the waveform becomes cluttered or unstable during the patient's ECG signal
acquisition, see Chapter 8.
4.2.23.2 Manual mode
Manual mode means that the user can manually control the duration of the ECG machine to
collect and print the ECG. It is generally used by the user to collect and print ECG waveform of
any length according to clinical needs.
Specific operation method:
1. In the waveform acquisition interface, set the gain, and paper speed according to actual
needs;
2. In the 【Recorder Setting】Interface，set the layout according to actual needs;
