Chapter 7 Monitor
ZyWALL USG Series User’s Guide
204
7.4 The Traffic Statistics Screen
Click Monitor > System Status > Traffic Statistics to display the Traffic Statistics screen. This screen provides
basic information about the following for example:
• Most-visited Web sites and the number of times each one was visited. This count may not be accurate
in some cases because the Zyxel Device counts HTTP GET packets. Please see Table 39 on page 205
for more information.
• Most-used protocols or service ports and the amount of traffic on each one
• LAN IP with heaviest traffic and how much traffic has been sent to and from each one
You use the Traffic Statistics screen to tell the Zyxel Device when to start and when to stop collecting
information for these reports. You cannot schedule data collection; you have to start and stop it
manually in the Traffic Statistics screen.
Status This field displays the current status of the interface.
• Down - The interface is not connected.
• Speed / Duplex - The interface is connected. This field displays the port speed and duplex
setting (Full or Half).
This field displays Connected and the accumulated connection time (hh:mm:ss) when the PPP
interface is connected.
TxPkts This field displays the number of packets transmitted from the Zyxel Device on the interface
since it was last connected.
RxPkts This field displays the number of packets received by the Zyxel Device on the interface since it
was last connected.
Tx B/s This field displays the transmission speed, in bytes per second, on the interface in the one-
second interval before the screen updated.
Rx B/s This field displays the reception speed, in bytes per second, on the interface in the one-second
interval before the screen updated.
Table 38 Monitor > System Status > Interface Status (continued)
LABEL DESCRIPTION
