Chapter 7 Monitor
ZyWALL USG Series User’s Guide
216
7.11.1 More Information
This screen displays more information on your mobile broadband, such as the signal strength, IMEA/ESN
and IMSI that helps identify your mobile broadband device and SIM card. Click Monitor > System Status
> Cellular Status > More Information to display this screen.
Note: This screen is only available when the mobile broadband device is attached to and
activated on the Zyxel Device.
Figure 178 Monitor > System Status > Cellular Status > More Information
The following table describes the labels in this screen.
Cellular System This field displays what type of cellular network the mobile broadband connection is
using. The network type varies depending on the mobile broadband card you inserted
and could be UMTS, UMTS/HSDPA, GPRS or EDGE when you insert a GSM mobile
broadband card, or 1xRTT, EVDO Rev.0 or EVDO Rev.A when you insert a CDMA
mobile broadband card.
Signal Quality This displays the strength of the signal. The signal strength mainly depends on the
antenna output power and the distance between your Zyxel Device and the service
provider’s base station.
Table 48 Monitor > System Status > Cellular Status (continued)
LABEL DESCRIPTION
Table 49 Monitor > System Status > Cellular Status > More Information
LABEL DESCRIPTION
Extension Slot This field displays where the entry’s cellular card is located.
Service Provider This displays the name of your network service provider. This shows Limited Service if the
service provider has stopped service to the mobile broadband card. For example if the
bill has not been paid or the account has expired.
Cellular System This field displays what type of cellular network the mobile broadband connection is
using. The network type varies depending on the mobile broadband card you inserted
and could be UMTS, UMTS/HSDPA, GPRS or EDGE when you insert a GSM mobile
broadband card, or 1xRTT, EVDO Rev.0 or EVDO Rev.A when you insert a CDMA mobile
broadband card.
