Chapter 10 Interfaces
ZyWALL USG Series User’s Guide
340
Figure 256 Configuration > Network > Interface > Cellular
The following table describes the labels in this screen.
Table 115 Configuration > Network > Interface > Cellular
LABEL DESCRIPTION
Add Click this to create a new cellular interface.
Edit Double-click an entry or select it and click Edit to open a screen where you can modify the
entry’s settings.
Remove To remove an entry, select it and click Remove. The Zyxel Device confirms you want to remove
it before doing so.
Activate To turn on an entry, select it and click Activate.
Inactivate To turn off an entry, select it and click Inactivate.
Connect To connect an interface, select it and click Connect. You might use this in testing the interface
or to manually establish the connection.
Disconnect To disconnect an interface, select it and click Disconnect. You might use this in testing the
interface.
References Select an entry and click References to open a screen that shows which settings use the entry.
See Section 10.5.4 on page 328 for an example.
# This field is a sequential value, and it is not associated with any interface.
Status The activate (light bulb) icon is lit when the entry is active and dimmed when the entry is
inactive.
The connect icon is lit when the interface is connected and dimmed when it is disconnected.
Name This field displays the name of the interface.
Description This field displays the description of the interface.
Extension Slot This field displays where the entry’s cellular card is located.
Connected
Device
This field displays the name of the cellular card.
ISP Settings This field displays the profile of ISP settings that this cellular interface is set to use.
