MANUGENX5 - Version 1.01 24.03.2021
© 2021 0N3 s.r.l. - Subject to change without notice
17
If the switch is pushed all the way in and then released it goes directly to the Null state skipping the Enable position.
CAUTION!
• User is responsible for interfacing the system to the machine control logic and implementing the En-
abling function according to the safety level determined in a previous risk analysis.
• The enable switch fulls its protective function only if the operator can recognize the danger in time.
• The Enabling Button and its related relays are Safety Modules, subjected to internal functional tests.
In case of hardware failure the Safety FSM enters Emergency state.
• In case of dangerous states the logic controller, another conscious start command should be required
to allow activation additionally to the enable switch.
• The only person permitted in the dangerous area is the person activating the enable switch.
• User can always access through the HMI to all diagnostics information about the safety module built
up by the Wireless Handheld and Base Station. In case of faults or failures user must always refer to
0N3 S.r.l for maintenance and repair operations.
i
INFORMATION
• The enabling function is implemented with:
- the Enabling Button;
- the logic circuits on the Wireless Handheld that monitor the Enabling Button status and transmit
it to the Base Station;
- the logic circuits on the Base Station that receive the Enabling Button status and replicate it on
the safety relays.
