Installation manual 2N® IP Verso
183 / 241
Module Externally mounted
(visible module)
Internally mounted
(invisible module)
Internally mounted on
bottom base edge
Touch display X
Induction loop X
Fingerprint reader X
I/O module X
5-button X
OSDP X
Wiegand X
Tamper switch X
Blind X
Security Relay X
Module Power Supply
With the exception of the Tamperswitch module, all the2N
®
IP Versomodules are powered
from the bus. The available bus power output depends on the power supply type. Main units
571v3 and higher can use a 3A power supply to increase the bus power available for the modules
connected.
Power supply Specification Available power
External supply 12 V ±15%/ 2 A (3 A) 24 W (36 W)
PoE 802.3af (Class 0–12.95 W) 12 W
Combined External supply + PoE 30 W (42 W)
The count of modules on the bus is limited by the available power supply output. The maximum
count of the modules on the bus is 30.
